AX7C10CG250E
Camera 31MP
The iRayple AX7C10CG250E is a 31 MP colour GigE industrial camera. It is built on the Sony - IMX342 (22.3 mm x 16.7 mm CMOS) sensor with a global shutter and reads out 6464 × 4852 at 3.6 fps. It takes M58 x 0.75 optics and connects over GigE. It draws 24 V ≈ 7.86 W and operates from -30℃~+50℃. The body measures 72 mm x 72 mm x 64 mm and weighs 487 g.
- Series Type
- Large Camera
- Sensor
- 22.3 mm x 16.7 mm CMOS
- Image Sensor
- Sony - IMX342
- Shutter
- Global
Engineered for precise industrial imaging
- Gigabit Ethernet interface, with a maximum transmission distance of 100m
- A patented flatness mediation scheme to eliminate area defocusing
- Excellent heat dissipation design, precise temperature control and constant temperature maintenance
- Support Software Trigger/Hardware Trigger/Free Run Mode
- Support user-defined ROI, horizontal mirroring and vertical mirroring
- Support ISP functions including Auto Exposure/Auto Gain/Auto BlackLevel/Gamma Correction and LUT
- Color cameras support automatic white balance
- Support for FFC function to provide more uniform picture quality
- Support fan speed adaptive function for setting the target temperature of the sensor
- Conform to GigE Vision V2.0 protocol and GenICam standard
- Support DC 24V power supply
- Conform to CE, KC, RoHS
Product parameters
The large area scan camera is the high-end series of iRAYPLE area scan cameras that offer resolutions ranging from 5 MP to 604 MP and are designed to provide high resolution, high frame rate, and high image quality. An excellent ISP algorithm is utilized to ensure optimal image effects. Some models also have TEC cooling capabilities, which help maintain a stable temperature for the sensor. This makes them well-suited for industries such as EV, photovoltaic, semiconductor, liquid crystal, and more.
Basic
- Series Type
- Large Camera
- Sensor
- 22.3 mm x 16.7 mm CMOS
- Image Sensor
- Sony - IMX342
- Shutter
- Global
- Resolution
- 6464 × 4852
- Frame Rate
- 3.6 fps
- Bit Depth
- 12
- Type
- Color
- Pixel Size
- 3.45 μm × 3.45 μm
- Image Format
- Mono8, BayerRG8/10/10Packed/12/12Packed, BayerGB8/10/10Packed/12/12Packed, YUV422 Packed
- Binning
- 1 x 2,2 x 1,2 x 2
- Dynamic Range
- 73 dB
- ROI
- Support
- X Flip
- Support
- Y Flip
- Support
- Gain
- 1～32
- Exposure Time
- 3 μs ~ 15 s
- Trigger Mode
- Software Trigger/Hardware Trigger/Free Run Mode
- SPC
- Support
Performance
- User Setting
- Support two sets of user-defined configurations
- Image Buffer
- 512 MP
Communication
- Interface
- GigE
- Mount
- M58 x 0.75
Power Supply
- Input Voltage
- DC 24V power supply via the 12-pin Hirose interface
- Power
- 24 V ≈ 7.86 W
Environment
- Operating Temperature
- -30℃~+50℃
- Storage Temperature
- -30℃~+80℃
Mechanical
- Dimensions
- 72 mm x 72 mm x 64 mm ( (not including the rear case connector)
- Weight
- 487 g
Compact housing dimensions
72 mm x 72 mm x 64 mm
