Smart CodeLogistics Code - DH-SL24A2R-S2E
iRayple · Smart Code

DH-SL24A2R-S2E

Logistics Code

The iRayple DH-SL24A2R-S2E is a 12 MP monochrome smart code. It uses a rolling shutter and reads out 4000 × 3000 at 15 fps. It draws ≤15.8W from DC24V and operates from -20℃～+50℃x. It weighs Net: <1500 g - Gross: <1900 g.

Series Type
Logistics Code
Resolution
4000 × 3000
Frame Rate
15 fps
Shutter
Rolling
In stockModel: DH-SL24A2R-S2E
Get a quote
Performance highlights

Engineered for precise industrial imaging

  • Easy installation and convenient operation.
  • Gigabit Ethernet interface can reach a maximum transmission distance of 100 meters.
  • Supports multiple trigger modes including software trigger, external trigger, and free operation.
  • Rich IO interfaces, supporting one non-isolated GPIO for configurable input and output.
  • Supports C-mount lenses.
  • DC24V operating environment.
  • Built-in code reading algorithm with high recognition rate and fast speed.
  • Uses 24 high-brightness LED lights, center illumination 11000lux@ 1000mm, providing even fill light.
DH-SL24A2R-S2EGet a quote
