IT7070T
HMI 7inch
The Inovance IT7070T is a 0.3 MP HMI. It runs on 24VDC ±20%. The body measures 200mm x 146mm x 35mm.
- Series Type
- IT Series
- Model
- IT7070T
- Screen Type
- High-preformance
- Window Size
- 7"
In stockModel: IT7070T
Performance highlights
Engineered for precise industrial imaging
- User friendly InoTouchPad PC configuration software (Windows 10 compatible)
- Javascript for creation of plug-ins and dedicated communication protocols, & access to external databases
- Serial port and/or Ethernet stand alone and multi-device networking
Technical data
Product parameters
High-end functionality and connectivity Easy integration with any machine control system
Basic
- Series Type
- IT Series
- Model
- IT7070T
- Screen Type
- High-preformance
- Window Size
- 7"
- Memory
- CPU: Cortex A8 600MHz - Flas & DRAM: 128MB
Display
- Resolution
- 800 x 400
- Brightness
- 350(cd/m2)
- Colors
- 24-bit true colour
- Backlight Life
- 35,000 hrs
Interface
- Communication
- RS232/RS485
- Communication Support
- USB2.0, Mini USB
- Ethernet Port
- None Support
- COM Port
- COM1: (RS422/RS485) - COM2: (RS232)
- USB Port
- USB 2.0 interface x 1 - Mini USB interface x 1
Power Supply
- Input Voltage
- 24VDC ±20%
Environment
- Protection Class
- Front panel IP65, back cover IP20
Mechanical
- Dimensions
- 200mm x 146mm x 35mm
Mechanical drawing
Compact housing dimensions
200mm x 146mm x 35mm
